Xtreme Power Conversion M90
Modular Online UPS // 208/120VAC Three-Phase
The M90 is a scalable modular online UPS that protects critical data and equipment from power problems while supplying clean and reliable network grade power.
The M90 can be configured with a fully redundant power module and battery modules. Should one module fail, the remaining modules smoothly take over the load. Because the power modules are independent, they can be hot swapped without risk to the critical load.
As power requirements change, M90 modularity makes it easy to add modules and increase capacity.
Product Snapshot
- Six capacities: 15kVA/13.5kW, 20kVA/18kW, 30kVA/27kW, 40kVA/36kW, 45kVA/40.5kW, 60kVA/54kW
- Modular for capacity or redundancy
- Hot swappable power modules
- Up to 98% ECO mode or 94% online efficiency
- Remote control and monitoring options
- 2 year electronics, 2 year battery warranty (USA and Canada)
The M90 is ENERGY STAR certified.
Energy Star Certified M90 can be a vital piece of equipment if the end user is pursuing Leadership in Energy and Environmental Design (LEED), Green Globes, or the U.S. Guiding Principles for High Performance and Sustainable Buildings, ENERGY STAR certification will ensure your building uses less energy and leaves a smaller carbon footprint M90 & M90L provide best-in-class energy efficiency, lowest energy consumption and heat output. ENERGY STAR is a U.S. Environmental Protection Agency (EPA) voluntary program that helps businesses and individuals save money and protect our climate through superior energy efficiency. More than a mark of energy efficiency.
Specifications
| MODEL NUMBER | M90-15 | M90-20 | M90-30 | M90-40 | M90-45 | M90-60 | |
|---|---|---|---|---|---|---|---|
| INPUT | Capacity | 15kVA (13.5kW) | 20kVA (18kW) | 30kVA (27kW) | 40kVA (36kW) | 45kVA (40.5kW) | 60kVA (54kW) |
| Nominal | 208/120V 50/60Hz auto sensing | ||||||
| Range | 121-253VAC*(L-L) 40-70Hz | ||||||
| OUTPUT | Voltage | 208/120VAC | |||||
| Frequency | 50/60 ± 0.05Hz | ||||||
| THD (full load) | 0.9 | ||||||
| Voltage regulation | Less than 2% | ||||||
| Efficiency | 98% ECO mode, ≥ 94% online mode | ||||||
| Overload capacity | 105%-110% for 60 min;110%-125% for 10min; 126%-150% for 1min; Less than 150% for 200ms | ||||||
| BATTERY SYSTEM | Nominal voltage | ±120V | |||||
| Temperature compensationNominal voltage | Yes with optional sensor | ||||||
| Charging current (programable) | 8A | 16A | 24A | 8A | 16A | 24A | |
| PHYSICAL | Enclosure | 20.3"W x 39.4"D x 54"H/484 lbs | |||||
| Power module | 19.0”W x 28.0”D x 5.1”H / 74 lbs | ||||||
| Battery module | 4.1”W x 28.3”D x 6.0”H / 68 lbs | ||||||
| ENVIRONMENT | Temperature | 0–40°C (32–104°F) | |||||
| Altitude | 5,200 ft above sea level | ||||||
| Audible noise | Less than 65dBA at 1m | ||||||
| APPROVALS | UL-1778 (TUV), cUL, FCC A, RoHS, Energy Star Certified | ||||||
| WARRANTY | 2 years (USA and Canada) | ||||||
| COMMUNICATIONS INTERFACE | RS-232, EPO, intelligent slot for optional cards (Web/SNMP, Relay, Modbus) | ||||||
| INCLUDED IN BOX | User manual, RS-232 cable, Ramp for unloading UPS enclosure | ||||||
| AVAILABLE OPTIONS | External maintenance bypass, 480V input transformer, output distribution, battery temperature sensor | ||||||
